Tinplate Available Specifications and Sizes
| Applicable Standard | JIS G 3303, EN 10202, ASTM A623/A624 | ||
|---|---|---|---|
| Black plate | SR | DR | |
| Normal thickness(mm) | 0.17～0.50 | 0.15～0.38 | |
| Normal Width(mm) | 700～1030 | 700～960 | |
| Length(sheet) (mm) | 601～1200 | 601～1200 | |
| Steel grade | MR, SPCC | ||
| Temper grade | T1 T-2 T-2.5 T-3 T-3.5 T-4 T-5 | DR-7M DR-8 DR-8M DR-9 | Refer to temper comparison chart below |
| Coating Weight | 1.1～11.2(g/M2) for tinning, 80-120mg/M2 for chroming | ||
| Surface Finish | B(Bright) R(Stone) S(Silver) | ||
| Surface treatment | Passivation 311 | ||
| Annealing | BA | ||
| Oiling | DOS(2-20mg/M2) | ||
| Max outer diameter (mm) | 2000 | ||
| Coil inner diameter (mm) | 420/508 | ||
| Weight range(MT) | 3～10(for coil), 1.5-2 (for sheets) | ||
Note: Other than above maybe applied if agreed with between the purchaser and the supplier
