Zn Al Mg steel sheet

Thickness:0.27-4.0mm

Width:600-1500mm

Zinc: 40-300g

Inner diameter: 508/610mm

Packing:Export seaworthy package or according to requirement

Products

17 years steel export experience.

What is Zn Al Mg steel sheet?

Zn Al Mg steel sheet a new type of highly corrosion-resistant coated steel sheet with a coating composition consisting of zinc as the main substrate in combination with aluminum (about 11%), magnesium (about 3%) and a trace amount of silicon. Adding Al, Mg, and Si to SuperDyma, the composite effect of these added elements improves corrosion resistance.

Application for Zn Al Mg steel sheet

Road/Civil engineering	Bridge reinforcing plate, soundproof wall, wind barrier panel, sound barrier(backside), sound barrier(front side), sound barrier member, snow fence, guardrail, bridge railing, pipe for joining bolt of concrete block, rock bolt, windbreak screen, drain reinforcement pipe, handrail in the tunnel, steel pipe pile, fireproof protection for optical fiber.
Farming	Greenhouse, compost house, grape arbor prop, cropper, fish preserve(frame)
Railroad	Sound barrier louver(station building), ventilation duct for the train depot, cable bracket, cable duct, inner panel of platform door.
Electric power and electric equipment	Solar battery module frame, Power control board, Air conditioning unit, Switchboard, Cable rack
Construction	Refrigerant duct, ceiling crosspiece, indoor baseball field, sound barrier louver, heavy-duty shutter, house frame
Automobile parts	Wiper linkage, Filter case, radiator fan motor cover, starter motor yoke, horn, pulley, hood lock, splash guard, battery module, cover for HEV, constant velocity joint cover, tank heat protector, window regulator motor yoke, lower sash.
Housing	Antenna mounting bracket, grounding rod, EV charger, Structural material for residential house, joint metal, structural material for housing, mounting strap, fuel tank for an oil fan heater, trestle for outdoor unit of an air conditioner(unpainted, painted), Bottom plate for outdoor unit of air conditioner, window anchor, door supporter.
Others	Multistory mechanical parking garage, bicycle racks, fire-hydrant cabinet, self-propelled multistory parking garage(distant view), deck plate for the parking lot(enlarged view)

Advantage of Zn Al Mg steel sheet

* Zn Al Mg steel sheet is 5~8 times the corrosion resistance of the flat part of the galvanized steel plate.
* The unique cut-off coating self-healing anti-corrosion performance.
* Ihe excellent acid and alkali corrosion resistance, and can replace stainless steel in some fields.
* The better abrasive resistance than GI and GL.
* Machinability stability under severe conditions, can replace the hot-dip galvanized plate.
* Environmentally and friendly products. It doesn’t contain heavy metal ions. Meet ROHS standards

Zn Al Mg steel sheet has better anti-corrosion performance than GI and GL. The ability of cutting port protection is good. Its welding performance is also deserved to be mentioned. It could be even a good replace for stainless steel from some parts.

GRADE FOR Zn Al Mg steel sheet

Packing

Packaging Details：

1.Each bare coil to be securely tied with two bands through the eye of coil (or not) and one circumferential.
2.the contact points of these bands on the coil edge to be protect with edge protectors.
3.Coil then to be properly wrapped with water proof /resistant paper, it then to be properly and completely metal wrapped.
4.Wooden and iron pallet can be used or as your requirements.
5.And each packed coil to be properly wrapped with band, three-six such band through the eye of coil at about equal distance

Loading

Port：Qingdao port, Shanghai port, Tianjin port

Lead Time：7-30 days after receiving deposit

Our Service For You

1). Free sample can be offered.
2).Short delivery time,afer deposite 7–30 days.
3).Good Quality + Manufacturer competitive price + Quick Response + Reliable Service, is what we are trying best to offer you
4). All of our products are produce by our professional workman and we have our high-work-effect foreign trade team, you can totally believe our service.
5). We have 6 years experience in this field, our customers are from all over the world.

Q/BQB 425-2004	AS 1397-2001	EN 10215-1995	ASTM A792M-02	JIS G3321:1998	ISO 9364-2001
DC51D+ZAM	G2+ZAM	DX51D+ZAM	CS Type B Type C	SGLCC	01
DC52D+ZAM	G3+ZAM	DX52D+ZAM	DS	SGLCD	2
S250GD+ZAM	G250+ZAM	S250GD+ZAM	255	--	250
S300GD+ZAM	G300+ZAM	--	--	--	--
S350GD+ZAM	G350+ZAM	S350GD+ZAM	345 Class1	SGLC490	350
S550GD+ZAM	G550+ZAM	S550GD+ZAM	550	SGLC570	550
